Description
ギガビット 5ポート産業用スイッチングハブ
広い動作温度範囲-30℃〜75℃で、過酷な環境下でも長時間に安定動作が可能なコンパクト産業用スイッチングハブ
Product features
Plug & Play, Gigabit Fast Switching
動作温度が-30~75℃に対応、過酷な環境でも使用可能
Lightning surge protection 5000A (8/20μs)
![](https://infipwr.com/wp-content/uploads/2020/01/Thunder.jpg)
DC12V to 52V power supply compatible, reverse connection protection
Long life, high reliability
![](https://infipwr.com/wp-content/uploads/2022/11/LongLife.jpg)
Easy mounting with integrated DIN rail bracket
Various EMS and EMI certifications for high durability
Aluminum case for easy heat dissipation, fanless specification
All ports support AUTO-MDIX and AUTO-Negotiation
![](https://infipwr.com/wp-content/uploads/2022/11/Auto-negociation.jpg)
Specification
Color | black |
Compliance standard | IEEE802.3(10BASE-T)、IEEE802.3u(100BASE-TX/FX )、IEEE802.3ab(1000BASE-T)、IEEE802.3z1000Base-X;IEEE802.3x; IEEE802.3af, IEEE802.3at |
Compliant standard | EMI: FCC Part 15 Subpart B Class A, EN 55022 Class A EMS: IEC (EN) 61000-4-2 (ESD): ±8kV contact discharge, ±12kV air discharge IEC(EN)61000-4-3(RS): 10V/m(80~1000MHz) IEC(EN)61000-4-4(EFT) : Port: ±4kV CM//±2kV DM; IEC(EN)61000-4-5(Surge) : Port : ±4kV CM//±2kV DM ; IEC(EN)61000-4-6(Induced RFI): 3V(10kHz~150kHz), 10V(150kHz~80MHz) IEC(EN)61000-4-16(Common mode) : 30V cont. 300V,1s IEC (EN) 61000-4-8 (Magnetic field) Shock: IEC 60068-2-27 Freefall: IEC 60068-2-32 Vibration: IEC 60068-2-6 |
Switching method | Store & Forward |
Maximum transmission speed | 1000Mbps (1000BASE-T) |
Port configuration | 1000BASE-T/100BASE-TX/10BASE-T (RJ-45) x 5 ports |
Jumbo frame | Correspondence |
Buffer memory | 1.2Mb |
MACaddress table | 2K |
Size | W105×D74×H30mm |
Weight | about 360g |
Power consumption | Max/3W |
Operating environment | Operating temperature/-30 to 75°C, operating humidity/5 to 95% (non-condensing) Storage temperature/-40 to 75°C, storage humidity/5 to 95% (non-condensing) |
MTBF | 380,000 hours (35°C) |
Number of ports | 5 ports |
Communication mode | Full Duplex/Half Duplex |
Switch fabric | 14Gbps |
Maximum packet forwarding capacity | 7.44 Mpps |
Auto MDI/MDI-X | Correspondence |
Auto negotiation | Correspondence |
Power supply | terminal block |
Input voltage | 12 to 52 VDC |
Input current protection | 4A |
Housing material | aluminum alloy |
Compatible DIN rail | Yes (35mm) |
Fan specifications | silent fanless |
Dust proof standard | IP40 |
